1 Classic Glass Sunroom

SP-SR-100 — 100-series aluminum glass sunroom with full wood-grain transfer finish. Classic pitched and hip roof configurations. Thermal-break profile with 6+12A+6 Low-E insulating glass. Ideal for villa extensions, garden rooms and residential conservatories.

Factory Direct Price — MOQ 1 Set

From $2,400 / set

Price varies by dimensions, configuration and finish. Contact us for a detailed quote.

Heading

Frame Material

6063-T5 Aluminum Alloy

Surface Treatment

AkzoNobel Powder Coat + Wood-Grain Transfer, 60μm

Louver Adjustment

N/A

Wind Load Rating

Class 7 (100 km/h)

Snow Load Rating

120 kg/m²

Service Life

30-50 Years

Lead Time

35–50 Days

Get a Free Quote

Get a Free Quote

Partner Program

Partner Program

Product Features

Precision.
Performance.

Adjustable Shade

Control sunlight and ventilation by adjusting louver angles from 0° to 135°. From full sun to complete shelter in seconds.

Weather Sealed

Integrated gutter channels rainwater efficiently. EPDM seals prevent water ingress at all articulation points.

Wind & Snow Rated

Engineered structural performance: wind up to 120 km/h, snow load up to 150 kg/㎡. Certified to international standards.

Modular Assembly

Pre-fabricated components for fast, clean installation. Minimal on-site work required. Compatible with standard construction practices.

Premium Finishes

Powder coating in standard RAL colors. Wood grain transfer printing available. Custom colors on request.

Sustainable

100% recyclable aluminum. AkzoNobel water-based powder coating. Minimal environmental footprint across the full lifecycle.

Technical Specifications

Built to
Exacting Standards

Standard Dimensions

Width: 3,000mm – 12,000mm
Projection: 2,500mm – 6,000mm
Eave Height: 2,200mm – 3,000mm
All dimensions fully customizable

Frame System

6063-T5 aluminum alloy, 1.4–2.0mm wall thickness
100-series main beam profiles
PA66 thermal-break strip
EPDM dual-durometer perimeter seals
316 stainless steel hardware throughout

Roof Style Options

Classic pitched roof
Hip roofconfiguration
Flat + sloped combination
A-frame gable
Custom ridge height on request

Glass Options

Clear: 6+12A+6 insulating glass (standard)
Low-E: 6+12A+6 with Low-E coating
Upgrade: 8+16A+8 triple comfort
Laminated safety glass option
Smart glass (PDLC) on request

Surface Finishes

Walnut wood grain (standard)
Mahogany / Teak wood grain
RAL 9005 Jet Black solid
RAL 9010 Pure White solid
Custom RAL on request

Classic Glass Sunroom
