8 Great Wall Plate Flat Carport

SP-CP-FPModern flat-roof aluminum carport using the Great Wall plate (长城板) ribbed panel system. Clean horizontal silhouette, solid aluminum roof, integrated concealed gutter. Cantilever and post-supported configurations. The premium choice for contemporary residential and commercial parking facilities.

Factory Direct Price — MOQ 1 Set

From $1,800 / set

Price varies by dimensions, configuration and finish. Contact us for a detailed quote.

Heading

Frame Material

6063-T5 Aluminum Alloy

Surface Treatment

AkzoNobel Powder Coat, 60μm

Louver Adjustment

N/A — Fixed Flat Plate Roof

Wind Load Rating

Class 8 (120 km/h)

Snow Load Rating

150 kg/m²

Service Life

30-50 Years

Lead Time

30–40 Days

Get a Free Quote

Get a Free Quote

Partner Program

Partner Program

Product Features

Precision.
Performance.

Adjustable Shade

Control sunlight and ventilation by adjusting louver angles from 0° to 135°. From full sun to complete shelter in seconds.

Weather Sealed

Integrated gutter channels rainwater efficiently. EPDM seals prevent water ingress at all articulation points.

Wind & Snow Rated

Engineered structural performance: wind up to 120 km/h, snow load up to 150 kg/㎡. Certified to international standards.

Modular Assembly

Pre-fabricated components for fast, clean installation. Minimal on-site work required. Compatible with standard construction practices.

Premium Finishes

Powder coating in standard RAL colors. Wood grain transfer printing available. Custom colors on request.

Sustainable

100% recyclable aluminum. AkzoNobel water-based powder coating. Minimal environmental footprint across the full lifecycle.

Technical Specifications

Built to
Exacting Standards

Standard Configurations

Single: 3,600mm × 5,000mm
Double: 5,500mm × 5,500mm
Multi-bay: custom span × depth
Post spacing: 3,000–6,000mm
Cantilever option: no front posts

Structural System

6063-T5 aluminum, 2.0–3.0mm wall
200×200mm square column posts
120×80mm main crossbeam
Great Wall plate panels (AF-73 series)
Wind Class 8, snow 150 kg/m²

Great Wall Plate System

Panel width: 950mm per unit
Rib height: 45mm
Upper & lower facing: 0.6mm each
Tongue-and-groove concealed joint
Accessories: AF-74 sealing cover, AF-75 cornice

Color Options

RAL 7016 Anthracite (standard)
RAL 9005 Jet Black
RAL 9006 Silver Grey
RAL 9010 Pure White
Custom RAL on request
