02 Louvered Pergola

SP-PG-LV — Motorized adjustable louvered pergola system. 135mm aluminum louvers rotate 0°–135° for precise sun and rain control. Rain sensor, wind sensor and smart home integration. Somfy / Dooya motor options. Freestanding or wall-mounted. Ideal for residential terraces, hospitality and commercial outdoor spaces.

Factory Direct Price — MOQ 1 Set

From $2,800 / set

Price varies by dimensions, configuration and finish. Contact us for a detailed quote.

Heading

Frame Material

6063-T5 Aluminum Alloy

Surface Treatment

AkzoNobel Powder Coat

Louver Adjustment

Motorized, 0°–135°

Wind Load Rating

Class 8 (120 km/h)

Snow Load Rating

N/A (open louver configuration)

Service Life

30-50 Years

Lead Time

30–45 Days

Get a Free Quote

Get a Free Quote

Partner Program

Partner Program

Product Features

Precision.
Performance.

Adjustable Shade

Control sunlight and ventilation by adjusting louver angles from 0° to 135°. From full sun to complete shelter in seconds.

Weather Sealed

Integrated gutter channels rainwater efficiently. EPDM seals prevent water ingress at all articulation points.

Wind & Snow Rated

Engineered structural performance: wind up to 120 km/h, snow load up to 150 kg/㎡. Certified to international standards.

Modular Assembly

Pre-fabricated components for fast, clean installation. Minimal on-site work required. Compatible with standard construction practices.

Premium Finishes

Powder coating in standard RAL colors. Wood grain transfer printing available. Custom colors on request.

Sustainable

100% recyclable aluminum. AkzoNobel water-based powder coating. Minimal environmental footprint across the full lifecycle.

Technical Specifications

Built to
Exacting Standards

Standard Dimensions

Width: 2,400mm – 8,000mm
Projection: 2,000mm – 6,000mm
Height: 2,400mm – 3,200mm
All dimensions fully customizable

Louver System

Louver width: 135mm extruded aluminum
Rotation: 0° (fully open) to 135° (rain shed)
Motor: Somfy RS100 / Dooya DT82TV
Rain sensor: auto-close on detection
Wind sensor: auto-close at set threshold

Structural Components

6063-T5 aluminum, 2.0–3.0mm wall
200×200mm square column posts
160×80mm main beam
316 stainless steel hardware
Concealed LED channel in each rafter

Control Options

RF remote handset (standard)
Somfy TaHoma smart home hub
Dooya motor hub integration
Amazon Alexa / Google Home
App control (iOS & Android)

Surface Finishes

RAL 7016 Anthracite Grey (standard)
RAL 9005 Jet Black
RAL 9010 Pure White
Wood grain transfer on request
Custom RAL on request
