Wall-Mounted Polycarbonate Canopy
SP-CAN-A3/A4 — A3/A4 Professional villa shading canopy system. Wall-bracket mounted, curved polycarbonate awning providing weather protection over doors, windows, terraces and walkways. Integrated gutter, concealed wall fixings, quick installation. The essential residential and commercial entrance canopy.
Factory Direct Price — MOQ 1 Set
From $280 / set
Price varies by dimensions, configuration and finish. Contact us for a detailed quote.
Heading
Frame Material
6063-T5 Aluminum Alloy
Surface Treatment
AkzoNobel Powder Coat, 60μm
Louver Adjustment
N/A — Fixed Polycarbonate Panel
Wind Load Rating
Class 6 (90 km/h)
Snow Load Rating
N/A
Service Life
30-50 Years
Lead Time
15–25 Days
Product Features
Precision.
Performance.
Adjustable Shade
Control sunlight and ventilation by adjusting louver angles from 0° to 135°. From full sun to complete shelter in seconds.
Weather Sealed
Integrated gutter channels rainwater efficiently. EPDM seals prevent water ingress at all articulation points.
Wind & Snow Rated
Engineered structural performance: wind up to 120 km/h, snow load up to 150 kg/㎡. Certified to international standards.
Modular Assembly
Pre-fabricated components for fast, clean installation. Minimal on-site work required. Compatible with standard construction practices.
Premium Finishes
Powder coating in standard RAL colors. Wood grain transfer printing available. Custom colors on request.
Sustainable
100% recyclable aluminum. AkzoNobel water-based powder coating. Minimal environmental footprint across the full lifecycle.
Technical Specifications
Built to
Exacting Standards
A3 Series (Standard)
- Projection: 1,500mm – 2,000mm
- Width: custom (standard 1,000–6,000mm)
- Main beam: A3 section profile
- Wall bracket: concealed plate mount
- Suitable for: doors, windows
A4 Series (Extended)
- Projection: 2,000mm – 3,000mm
- Width: custom (standard 1,500–8,000mm)
- Main beam: A4 heavy section profile
- Optional front post support
- Suitable for: terraces, walkways
Material & Hardware
- 6063-T5 aluminum, 1.4–2.0mm wall
- 8mm twin-wall polycarbonate panel
- Stainless steel wall brackets
- EPDM seals at all junctions
- AkzoNobel powder coat finish
Color Options
- Bronze (standard — matches PC sheet)
- Silver RAL 9006
- Anthracite RAL 7016
- White RAL 9010
- Custom RAL on request
